Geomet Coating for Carbon Steel Fasteners
Introduction to Geomet Coating
Geomet Coating for Carbon Steel Fasteners is a widely adopted surface treatment technique in various industries such as automotive, aerospace, and construction. It offers superior corrosion resistance without the use of harmful hexavalent chromium. This article explores the essential aspects of Geomet coating including its application process, performance characteristics, advantages, and industries where it’s most often used.
What is Geomet Coating?
Definition and Process Overview
Geomet coating is an inorganic, non-electrolytic, water-based zinc-aluminum flake coating. It is applied via dipping or spraying and followed by a curing process under heat. As a type of sacrificial coating, Geomet forms a thin barrier layer that protects the underlying carbon steel by preventing contact with corrosive agents.
Technical Background
This coating technology was originally developed in the late 20th century as an environmentally friendly alternative to traditional electroplating methods. Over the years, it has become prevalent in the fastener industry due to its superior anti-corrosion capabilities and compliance with global environmental standards such as RoHS and ELV.
Common Uses and Applicable Fasteners
Geomet coating is compatible with various types of carbon steel fasteners. Here is a breakdown of its uses:
| Fastener Type | Application |
|---|---|
| Bolts and Screws | Automotive assemblies, engines |
| Nuts | Structural frameworks |
| Self-tapping Screws | Consumer electronics, white goods |
| Washers | Heavy-duty industrial machinery |
Key Industries
- Automotive
- Mechanical Engineering
- Construction
- Electronics
- Aerospace
Performance Characteristics of Geomet Coated Fasteners
Corrosion Resistance
- Excellent salt spray performance (1000+ hours without red rust)
- High humidity and chemical resistance
Aesthetic and Physical Quality
| Property | Description |
|---|---|
| Color | Matte silver-gray |
| Gloss | Low-reflective, industrial finish |
| Coating Uniformity | High; ensures optimal surface coverage |
Mechanical Considerations
- Surface Hardness: Moderate increase in durability
- Abrasion Resistance: Superior to untreated carbon steel
- Conductivity: Non-conductive, making it ideal for electrical insulation
Geomet Coating Process Flow
Pre-Treatment
- Degreasing to remove oil
- Mechanical or chemical rust removal
- Thorough cleaning and drying
Coating Application
- Dip-Spinning or Spraying
- Layering to build thickness
- Oven curing at 300-350°C
Post-Treatment
- Optional passivation
- Sealing for enhanced corrosion protection
Advantages and Limitations
Key Advantages
- Environmental Compliance: Free of hexavalent chromium
- Excellent durability with thin coating layer
- Uniform coverage, even in recessed areas
- High corrosion resistance without hydrogen embrittlement
Limitations
- Higher upfront cost compared to basic electroplating
- Requires precise temperature control during curing
- Not suitable for high-conductivity requirements
Comparison: Geomet vs. Zinc Electroplating
| Aspect | Geomet Coating | Zinc Electroplating |
|---|---|---|
| Corrosion Resistance | 1000+ hours | 240-360 hours |
| Environmental Impact | RoHS compliant | Often uses Cr6+ |
| Process Type | Non-electrolytic | Electrolytic |
| Surface Uniformity | Excellent | Moderate |
| Cost | Higher initial cost | Lower cost |
Industry Standards and Certifications
- ISO 10683: Fasteners – Non-electrolytically applied zinc flake coatings
- ASTM B117: Salt Spray Testing Standard
- RoHS & ELV: Environmentally compliant formulations
Environmental & Safety Considerations
- No use of toxic hexavalent chromium
- Compliant with European Union RoHS directive
- Lower workplace hazard compared to electroplating
Cost and Economic Value
| Factor | Geomet Coating |
|---|---|
| Initial Investment | Medium-High |
| Long-Term Savings | Reduced rust-related failures |
| Overall ROI | High in demanding environments |
