Carbon Steel Slotted Cone Point Set Screw
Product Overview
Slotted Cone Point Set Screw are precision-engineered fasteners designed to secure objects together without the use of a traditional nut. Their unique design features a slotted drive and a sharply tapered cone point that provides a strong, concentrated force for penetrating and holding against a target material. These screws are commonly manufactured using high-grade carbon steel, offering excellent strength, durability, and affordability.
With their effective holding strength, Slotted Cone Point Set Screw are the ideal choice in applications where alignment and anti-slip performance are critical. As a common element in mechanical assemblies, these fasteners are widely used in gear systems, pulleys, and shaft collars.
At Flybear Fastener, we manufacture Slotted Cone Point Set Screw to meet global standards and offer custom sizes, finishes, and packaging to suit a variety of industrial needs.
Product Specifications Table
| Feature | Detail |
|---|---|
| Product Name | Slotted Cone Point Set Screw |
| Material | Carbon Steel |
| Drive Type | Slotted |
| Thread Type | Full Thread – UNC/UNF/Metric |
| Point Type | Cone Point |
| Sizes Available | M3 to M12, 1/8″ to 3/4″ |
| Finishing Options | Zinc Plated, Black Oxide |
| Standards | DIN 553 |
Technical Parameters
| Parameter | Value Range |
|---|---|
| Tensile Strength | 600 – 1000 MPa |
| Hardness | HRC 28 – 40 |
| Torque Resistance | As per ISO 898 |
| Thread Accuracy | Class 6g / 6H |
| Operating Temp Range | -40°C to +300°C |
Material Introduction & Manufacturing Process
Carbon steel, our material of choice for Slotted Cone Point Set Screw, is known for its strength, machinability, and cost-efficiency.
The manufacturing process is comprised of the following steps:
- Raw Material Selection — Using high-quality carbon steel
- Cold Heading — Shaping the screw blank under high pressure
- Thread Rolling — Creating precise threads with accurate pitch
- Slotting — Milling the slotted drive with high accuracy
- Point Formation — Grinding the tapered cone point
- Heat Treatment — Boosting hardness and tensile strength
- Surface Finishing — Anti-corrosion coatings like black oxide or zinc
Typical Industries and Application Scenarios
Slotted Cone Point Set Screw are commonly used across a range of industries, including:
- Automotive: Securing rotating components on shafts
- Aerospace: Holding flight control levers in position
- Machinery: Gear and pulley mounting in equipment
- Electronics: Sensor fixation in precise locations
- Medical Devices: Fixation screws for assembly joints
- Renewable Energy: Turbine and generator component locking
These screws are selected for their ability to apply concentrated pressure at a specific point, ensuring locking and alignment.
Product Advantages & Competitive Edge
High-Quality Material
Flybear Fastener uses premium-grade carbon steel with exemplary mechanical properties.
Precision Engineering
Each screw is manufactured to strict tolerances, ensuring excellent thread fit and pointed tip geometry for consistent performance.
Advanced Coating
Our Black Oxide and Zinc finishes enhance corrosion resistance and extend product lifespan in harsh environments.
Customization
We offer custom production based on drawings or prototypes, delivered on demand and in batches.
Inventory and Delivery
With vast warehouse space and strict inventory controls, our order fulfillment is quick and efficient globally.
Dedicated Technical Support
From inquiry to post-sales support, our in-house team assists clients in application review, troubleshooting, and material selection.
Company Testing and Quality Control
To ensure our Slotted Cone Point Set Screw meet the highest industry benchmarks, Flybear Fastener deploys an extensive QC process including:
- Material certification checks
- Torque and tensile tests
- Thread gauge inspection (GO/NO-GO)
- Coating thickness tests
- Dimension verification with precision tools
- Metallurgical structure analysis
These inspections are backed by ISO9001 quality assurance standards.
Selection and Purchasing Guide
When selecting Slotted Cone Point Set Screw, consider the following:
- Application Load: Choose size and material based on load requirements
- Thread Type: Match screw threading with mating part threading
- Point Style: Cone point for high-pressure penetration
- Finish: Zinc for corrosion; black oxide for dry indoor settings
- Quantity: Bulk ordering offers cost efficiency
Reach out to contact us for technical consultations and quantity-specific quotations. Whether you need off-the-shelf items or customized STP components, Flybear Fastener is ready to deliver.
Conclusion: Flybear Fastener – Your Trusted Fastener Manufacturer
Slotted Cone Point Set Screw are a reliable and efficient solution for many mechanical fastening requirements. At Flybear Fastener , we strive to deliver products that reflect precision, durability, and performance. We always adhere to the ideology: “Quality First, Customer Always.”
We are dedicated to providing high-quality fastener products and one-stop solutions for your fastening demands. Explore our full catalog to find related solutions, or contact us today for industry-specific support and quotes.
Whether the need is large-volume industrial setups or unique prototyping needs, we have your fastening challenges covered.
